OP Poly Ø10.0mm, 0.50mm thick<br><br>Specification

OP Poly Ø10.0mm, 0.50mm thick

Specification



  • Diameter : Ø10.0mm
  • Thickness : 0.50 mm
  • Edges : Laser Cut
  • Edge Features : < 0.2 mm
  • Flatness (PV) (fringe @ 632nm) : <5
  • Laser Kerf : 3°
  • Lateral Tolerance : +0.1 / – 0.1 mm
  • Parallelism (µ/mm) : <0.4
  • Side 1, Roughness, Ra : polished, Ra < 15 nm, (over 1mm2)
  • Side 2, Roughness, Ra : polished, Ra < 15 nm, (over 1mm2)
  • Thickness Tolerance : +/- 0.05 mm

We understand that every project is unique, and we’re here to customize our products to meet your specific needs. Whether it’s size or technical specifications, we tailor our solutions to fit your requirements perfectly. Reach out us to discuss your needs and find the right solution. Inquiry Now

OVERVIEW OF OPTICAL COMPONENTS

Our custom optical components leverage the exceptional properties of diamond to deliver high-performance solutions for a variety of optical systems. Diamond’s superior hardness, high thermal conductivity, and exceptional clarity make it an ideal material for demanding optical applications.

Key Use Cases

High-Precision Optics Diamond lenses and windows are designed for applications requiring extreme precision and clarity.
Laser Systems Diamond's thermal stability ensures consistent performance in high-power laser systems.
Scientific Instruments Our custom diamond optics enhance the accuracy and reliability of various scientific and analytical instruments.

Key Benefits

  • Exceptional Clarity and Transparency
  • High Thermal Stability
  • Resistance to Abrasion and Corrosion
